Elastic Locking Gas Springs

Lockable Gas Compression Springs Elastic Locking 10 23
Rod D1Ø 10MM 0.39"
Cylinder D2Ø 23MM 0.91"

Stroke lengths (S): 20-800MM 0.79"-31.50"
Extended length EL1: Stroke (S)*2 + 77MM / 3.03" (shortest possible)
Extended length EL2: Stroke (S)*2 + 77MM / 3.03" + cylinder end fitting

Force (F1) range: 50-1300N 11.25-292Lbs

Rod: QPQ
Cylinder: Black

Speed: Normal/Slow/Fast
Working temperature: -30°C +80°C -22°F +176°F
Progression ( approx.): 41%

Part # 1605 Cylinder thread M8x1.25
Part # 1605 Part # 1605 cylinder threaded ends L: 9MM 0.35"
Extended Length (EL1/EL2): Stroke (S)*2 + 77MM/3.03" ( shortest possible )

Part # 1615 Eye ends E8
Part # 1615 Part # 1605 cylinder threaded ends A: M8x1.25
B: Ø8.1MM
C: 16MM
D: 20MM
E: 10MM

0.319"
0.63"
0.79"
0.39"
Extended Length (EL2): Stroke (S)*2 + 97MM/3.82" ( shortest possible )

Part # 1615.3 Eye ends E8.3
Part # 1615.3 Part # 1615.3 eye ends A: M8x1.25
B: Ø8.1MM
C: 16MM
D: 16MM
E: 10MM

0.319"
0.63"
0.63"
0.39"
Extended Length (EL2): Stroke (S)*2 + 93MM/3.66" ( shortest possible )

Part # 1615.4 Eye ends E8.4
Part # 1615.4 Part # 1615.4 eye ends A: M8x1.25
B: Ø8.1MM
C: 20MM
D: 16MM
E: 12MM

0.319"
0.79"
0.63"
0.98"
Extended Length (EL2): Stroke (S)*2 + 93MM/3.66" ( shortest possible )

Part # 1625 Clevis end C8
Part # 1625 Part # 1625 clevis ends d2: M8x1.25
d1: Ø8MM
B: 8MM
G: 16MM
L1: 42MM
L2: 32MM

0.315"
0.315"
0.63"
1.65"
1.26"
Extended Length (EL2): Stroke (S)*2 + 109MM/4.29" ( shortest possible )

Part # 1635 Angle ball joint A8
Part # 1635 Part # 1635 angle ball joint ends d2: M8x1.25
d2/1: M8x1.25
A: 30MM
d1: ball Ø13MM
L2: 16.5MM


0.79"

0.65"
Extended Length (EL2): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Part # 1635.3 Angle ball joint A8IN
Part # 1635.3 Part # 1635.3 angle ball joint ends d2: M8x1.25
d2/1: 5/16-18UNC
a: 30MM
d1: ball Ø13MM
L2: 16.5MM


1.18"

0.65"
Extended Length (EL2): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Options:

- Valve: V Option valve
- Rod protector: R Option rodprotector Stroke reduction 5MM
- Low temperature -45°C / -49°F A
- High temperature 200°C / 392°F B
- Extended thread length: Option extended thread length
- Cylinder end with groove: Option cylinder end with groove
- Private label P

Product Inquiry example:
Part # Stroke (S) MM/INCH Length (EL2) MM/INCH Force N/Lbs Speed Working temp Options
1615 250 / 9.84 598 / 23.54 300N / 68Lbs Normal Normal
Extended length (EL2) of a lockable gas compression spring is measured with rod fully extended and will change depending on type of actuator head. See category release systems for more information.
Thread piston rod: MF10x1x19MM.
Force (F1) measured with piston rod 5MM/ 0.20" compressed.
Progression rate will change depending on cylinder volume.
Connecting parts are interchangeable, go to product category connecting parts to view more options.
Please be adivsed that Extended Length EL2 will change depending on your choice of connecting parts.
