Gas Compression Springs

Gas Compression Springs Diameter D1 Ø 10MM - D2 Ø 23MM

Model 1023-GS

Gas compression spring 1023-GS specifications: dimensions, force range, stroke lengths, end fittings and available operating options.

Configurator

Enlarged technical drawing

Material
Steel, nitrogen filled
Made in
Vernon, BC, Canada
Quality documentation
ISO 9001:2015 certificate (2018–2020)

Part of Gas Compression Springs

Technical specifications

Dimensions, 1023-GS: technical specifications
Rod D1Ø10MM / 0.39"
Cylinder D2Ø23MM / 0.91"
Stroke lengths (S)20-800MM / 0.79" - 31.50"
Extended length EL1Stroke (S)*2 +47MM / 1.85" / shortest possible
Extended length EL2Stroke (S)*2 +47MM / + connecting parts
Force, 1023-GS: technical specifications
Force (F1) range30-1300N / 6.75-292Lbs
Behaviour, 1023-GS: technical specifications
DampingNormal/No/Increased
SpeedNormal/Slow/Fast
Working temperature-30°C +80°C / -22°F +176°F
Progression ( approx.)34%
Finish, 1023-GS: technical specifications
RodQPQ
CylinderBlack

End fittings, options and part numbers

Select any drawing to enlarge it.

Scroll horizontally to view all columns.

1023-GS: Part # 605: Threaded ends M8x1.25Request a quote for part # 605 (opens in a new tab)
L: 9MM0.35"
Extended length (EL): Stroke (S)*2 +47MM/1.85" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615: Eye ends E8Request a quote for part # 615 (opens in a new tab)
A: M8x1.25 B: Ø8.1MM C: 16MM D: 20MM E: 10MM0.319" 0.63" 0.79" 0.39"
Extended length (EL): Stroke (S)*2 +87MM/3.43" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615.3: Eye ends E8.9Request a quote for part # 615.3 (opens in a new tab)
A: M8x1.25 B: Ø8.1MM C: 16MM D: 22MM E: 5MM0.319" 0.63" 0.87" 0.20"
Extended length (EL): Stroke (S)*2 +91MM/3.58" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615.18: Eye ends E8.3Request a quote for part # 615.18 (opens in a new tab)
A: M8x1.25 B: Ø8.1MM C: 16MM D: 16MM E: 10MM0.319" 0.63" 0.63" 0.39"
Extended length (EL): Stroke (S)*2 +79MM/3.11" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615.25: Eye ends E8.12Request a quote for part # 615.25 (opens in a new tab)
A: M8x1.25 B: Ø8.1MM C: 10MM D: 22MM E: 5MM0.319" 0.39" 0.87" 0.20"
Extended length (EL): Stroke (S)*2 +91MM/3.58" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615Z: Eye ends ZamakRequest a quote for part # 615Z (opens in a new tab)
A: M8x1.25 B: Ø8.1MM/0.32"; Ø10.1MM/0.40"; Ø12.1MM/0.48" C1: 19MM C2: 13MM D: 16MM E: 12MM0.75" 0.51" 0.63" 0.47"
Extended length (EL): Stroke (S)*2 +79MM/3.11" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 615ZA: Eye ends ZamakRequest a quote for part # 615ZA (opens in a new tab)
A: M8x1.25 B: Ø8.1MM/0.32"; Ø10.1MM/0.40" C1: 18MM C2: 12.4MM D: 18MM E: 10MM0.71" 0.49" 0.71" 0.39"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 625: Clevis ends C8Request a quote for part # 625 (opens in a new tab)
d2: M8x1.25 d1: Ø8MM B: 8MM G: 16MM L1: 42MM L2: 32MM0.315" 0.315" 0.63" 1.65" 1.26"
Extended length (EL): Stroke (S)*2 +111MM/4.37" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635: Angle ball joint ends A8Request a quote for part # 635 (opens in a new tab)
d2: M8x1.25 d2/1: M8x1.25 a: 30MM d1: ball Ø13MM L2: 16.5MM1.18" 0.65"
Extended length (EL): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.1: Angle ball joint ends A8.1Request a quote for part # 635.1 (opens in a new tab)
d2: M8x1.25 d2/1: 5/16-18UNC a: 20MM d1: ball Ø10MM L2: 16.5MM0.79" 0.65"
Extended length (EL): Stroke (S)*2 +87MM/3.43" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.2: Angle ball joint ends A8.2Request a quote for part # 635.2 (opens in a new tab)
d2: M8x1.25 d2/1: 5/16-18UNC a: 25MM d1: ball Ø10MM L2: 16.5MM0.98" 0.65"
Extended length (EL): Stroke (S)*2 +97MM/3.82" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.3: Angle ball joint ends A8INRequest a quote for part # 635.3 (opens in a new tab)
d2: M8x1.25 d2/1: 5/16-18UNC a: 30MM d1: ball Ø13MM L2: 16.5MM1.18" 0.65"
Extended length (EL): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.4: Angle ball joint ends A8.4Request a quote for part # 635.4 (opens in a new tab)
d2: M8x1.25 d2/1: M10x1.50 a: 30MM d1: ball Ø13MM L2: 16.5MM1.18" 0.65"
Extended length (EL): Stroke (S)*2 +107MM/4.23" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.5: Angle ball joint ends A8.5Request a quote for part # 635.5 (opens in a new tab)
d2: M8x1.25 d2/1: M8x1.25 a: 25MM d1: ball Ø10MM L2: 16.5MM0.98" 0.65"
Extended length (EL): Stroke (S)*2 +97MM/3.82" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 635.7: Angle ball joint ends A8.7Request a quote for part # 635.7 (opens in a new tab)
d2: M8x1.25 d2/1: M8x1.25 a: 20MM d1: ball Ø10MM L2: 16.5MM0.79" 0.65"
Extended length (EL): Stroke (S)*2 +87MM/3.43" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 645: Nylon ball socket ends P8Request a quote for part # 645 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM0.71"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 645.18: Nylon ball joint ends P18Request a quote for part # 645.18 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM d2/1: M8x1.25 L2: 16.5MM0.71" 0.71" 0.65"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 645.19: Nylon ball joint ends P19Request a quote for part # 645.19 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM d2/1: 5/16-18UNC L2: 16.5MM0.71" 0.71" 0.65"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 655: Metal ball socket ends B8Request a quote for part # 655 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM0.71"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 656: Metal ball socket B13Request a quote for part # 656 (opens in a new tab)
d2: M8x1.25 a: 30MM d1: ball Ø13MM1.18"
Extended length (EL): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 655.18: Metal ball joint ends B18Request a quote for part # 655.18 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM d2/1: M8x1.25 L2: 16.5MM0.71" 0.71" 0.65"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 655.19: Metal ball joint ends B19Request a quote for part # 655.19 (opens in a new tab)
d2: M8x1.25 a: 18MM d1: ball Ø10MM d2/1: 5/16-18UNC L2: 16.5MM0.71" 0.71" 0.65"
Extended length (EL): Stroke (S)*2 +83MM/3.27" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 665: Metal ball socket ends B36Request a quote for part # 665 (opens in a new tab)
d2: M8x1.25 a: 25MM d1: ball Ø10MM0.98"
Extended length (EL): Stroke (S)*2 +97MM/3.82" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 665.1: Metal ball socket ends B32Request a quote for part # 665.1 (opens in a new tab)
d2: M8x1.25 a: 20MM d1: ball Ø10MM0.79"
Extended length (EL): Stroke (S)*2 +87MM/3.43" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 665.2: Metal ball socket ends B38Request a quote for part # 665.2 (opens in a new tab)
d2: M8x1.25 a: 30MM d1: ball Ø13MM1.18"
Extended length (EL): Stroke (S)*2 +107MM/4.21" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: Part # 667: Rod end bearings RB8Request a quote for part # 667 (opens in a new tab)
d3: M8x1.25 L1: 36MM d1: Ø8MM L2: 24MM1.42" 0.315" 0.94"
Extended length (EL): Stroke (S)*2 +97MM/3.82" ( shortest possible )

Scroll horizontally to view all columns.

1023-GS: options and accessories
- Reducible force:V
- Friction:FEL1/EL2 10MM longer
- Dust boot:D
- Rod protector:RStroke reduction 5MM
- Lockable protector:LStroke reduction 5MM
- Horizontal use:HEL1/EL2 increase
- Low temperature -50°C / -58°FA
- High temperature 200°C / 392°FB
- No end fittings:
- Extended thread length:
- Cylinder end with groove:
- Cylinder end with extended clevis:
- Private labelP

Scroll horizontally to view all columns.

1023-GS: Product Inquiry example:
Part #Stroke (S) MM/INCHLength (EL2) MM/INCHForce N/LbsDampingSpeedWorking tempOptions
615250 / 9.84587 / 23.11890N / 200LbsNormalNormalNormal
  • Extended length (EL) of a gas compression spring is calculated when piston rod is fully extended
  • Force (F1) measured with piston rod 5MM/ 0.20" compressed
  • Progression rate will change depending on cylinder volume
  • Connecting parts are interchangeable, make your own combination or go to product category connecting parts to view more options
  • Please be advised that Extended Length EL2 will change depending on your choice of connecting parts

Enlarged technical drawing
